ROTAN® HD Internal Gear Pump

ROTAN® HD Internal Gear Pump

The HD gear pump are specifically designed for difficult applications



Heavy Duty - Internal gear pumps in cast iron, for a wide range of viscous, non-corrosive liquids.



REQUEST QUOTE



HD pumps are specifically designed for difficult applications and those involving high viscosity liquids. They are known by their sturdy and simple construction and available with 90° angular configuration.



Capacity Range: Up to 250 m3/h / 1100 gpm
Speed: Up to 1750 rpm
Differential Pressure: Up to 16 bar / 232 psi
Suction Lift: Up to 0,5 bar / 7.25 psi vacuum while priming
Up to 0,8 bar / 11.6 psi vacuum while pumping
Viscosity Range: Up to 250,000 cSt
Temperature: Up to 250°C / 482° F
Pumping of:
  • Oil
  • Asphalt
  • Chocolate
  • Paint/Lacquer
  • Molasses
  • Soap
  • Additives
  • Polyol



  • Viscose
  • Sulphate soap
  • Maltose
  • Grease
  • Pitch
  • Base oil
  • Bitumen
  • Polyester

Key features and benefits

  • Flexible sealing options
  • “True” back pull-out design
  • Opposing inlet and outlet connections with oversized ports
  • Shaft supported by two ball bearings in single sealed configuration
  • Self-priming with large suction capabilities
  • Low NPSH requirements
  • Self-draining, integral safety relief valve
  • No speed reduction required in six smaller sizes
  • Complete heating/cooling jacketing available
