Magnetic Drive Pump

Centrifugal pumps with magnetic coupling
Up to 385 m³/h (1700 US gpm) at 60 Hz

Centrifugal pump with magnetic coupling designed for high energy-efficiency, enhanced safety and low maintenance. The Magnetic Drive pump is used within applications and markets where no pumping medium leakage is allowed.

Request quote

Product information

Magnetic drive pumps are common used in applications where no pumping media leakage is allowed.

They can pump the following materials:
Methanol / Ammonia, Ethanol, Hydrocarbons & Amine/Water Mixtures.

Methanol / Ammonia Fuel Supply System

Methanol / Ammonia Transfer

Methanol / Ammonia Bunkering

Methanol / Ammonia Production (PtX)

Centrifugal pump with magnetic coupling meet the requirements for:

Leak Prevention
High efficiency
Reduced Friction
Improved Reliability
Low Maintenance
Installation and serviceability
Energy Efficiency
Enhanced Safety
Environmental Benefits

Design Features

Magnetic Drive pumps use magnetic coupling to avoid leakage. By eliminating the need for expensive auxiliary shaft seal flush systems and minimising operational downtime for seal inspections or replacements, we provide a comprehensive solution that aligns with both safety and sustainability. With its compact design and small footprint, this pump offers convenient and flexible installation, particularly in enclosed spaces.

Technical data

Nominal diameter (DN)	25 to 125
Flow rate - 50 Hz	Up to 320 m³/h (1400 US gpm)
Flow rate - 60 Hz	Up to 385 m³/h (1700 US gpm)
Head	Up to 250 m (820 ft)
Pressure	Up to 25 bar
Temperature	Min. -40°C / Max. 120°C
Motor	Standard and EX motors
Viscosity Range	Min. 0.3 / Max. 300 cSt
Starting Method	VFD or direct online (DOL)
ATEX approved	Yes

Pumping of:

Methanol, Ethanol, Hydrocarbons (fuels), Ammonia & Amine/Water Mixtures.

Note:
The pumps are designed for pumping liquids without solid/clogging particles. These could cause premature failure of the pump bearings and/or mag-drive.

Drawings

ESL:

TSL:

Manuals
